线阵漫射光源
产品概述
本产品采用特殊处理方式使光源达到好的漫反效果，特别适合表面反光项目检测使用。
特点
◊光照度可达300, 000LUX-400, 000LUX.
◊白色光源色温6500K,正白，非常适合用于彩色线阵应用。
◊均匀性非常好。
◊超强散热设计，保证光源的稳定性。
应用领域
薄膜瑕疵检测
PCB板图案检测
纸张脏污检测
印刷质量检测
型号规格参数
|
产品型号 |
发光长度(mm) |
外形足寸 (长x宽x高mm) |
功率(w) |
|
GHLL100X-2HW/2HR/2HG/2HB-DF |
100 |
112x40x113 |
24 |
|
GHLL200X-2HW/2HR/2HG/2HB-DF |
200 |
212x40x113 |
48 |
|
GHLL300X-2HW/2HR/2HG/2HB-DF |
300 |
312x40x113 |
72 |
|
GHLL400X-2HW/2HR/2HG/2HB-DF |
400 |
412x40x113 |
96 |
|
GHLL500X-2HW/2HR/2HG/2HB-DF |
500 |
512x40x113 |
120 |
|
GHLL600X-2HW/2HR/2HG/2HB-DF |
600 |
612x40x113 |
144 |
|
GHLL700X-2HW/2HR/2HG/2HB-DF |
700 |
712x40x113 |
168 |
|
GHLL800X-2HW/2HR/2HG/2HB-DF |
800 |
812x40x113 |
192 |
|
GHLL900X-2HW/2HR/2HG/2HB-DF |
900 |
912x40x113 |
216 |
|
GHLL1000X-2HW/2HR/2HG/2HB-DF |
1000 |
1012x40x113 |
240 |
|
GHLL1100X-2HW/2HR/2HG/2HB-DF |
1100 |
1112x40x113 |
264 |
|
GHLL1200X-2HW/2HR/2HG/2HB-DF |
1200 |
1212x40x113 |
288 |
|
GHLL1300X-2HW/2HR/2HG/2HB-DF |
1300 |
1312x40x113 |
312 |
|
GHLL1400X-2HW/2HR/2HG/2HB-DF |
1400 |
1412x40x113 |
336 |
|
GHLL1500X-2HW/2HR/2HG/2HB-DF |
1500 |
1512x40x113 |
360 |
|
GHLL1600X-2HW/2HR/2HG/2HB-DF |
1600 |
1612x40x113 |
384 |
|
GHLL1700X-2HW/2HR/2HG/2HB-DF |
1700 |
1712x40x113 |
408 |
|
GHLL1800X-2HW/2HR/2HG/2HB-DF |
1800 |
1812x40x113 |
432 |
|
GHLL1900X-2HW/2HR/2HG/2HB-DF |
1900 |
1912x40x113 |
456 |
|
GHLL2000X-2HW/2HR/2HG/2HB-DF |
2000 |
2012x40x113 |
480 |
